100G QSFP28 To 4x 25G SFP28 Active Optical Cables 4x25G NRZ, 100Meters(328ft)
FIBERSTAMP 100G QSFP28 to 4x 25G SFP28 AOC active optical cable is used for short-distance interconnection between devices within the data center, conforming to IEEE 802.3bm 100GBASE-SR4 Ethernet transmission protocol and IEEE 802.3by 25GBASE-SR Ethernet transmission protocol. This series uses 4 pairs of parallel multimode fiber transmission with a center wavelength of 850nm and distances of up to 70m (OM3) or 100m (OM4).
Description
- An active optical cable assembly integrating one 100G QSFP28 SR4 and four 25G SFP28 SR optical transceiver modules at both ends
- Each side contains 4 channels of 850nm VCSEL and PIN
- The transmission rate per channel can reach up to 25.78125Gbps
- Receive and transmit channel built-in CDR circuit, support CDR bypass
- Comply with QSFP28/SFP28 MSA and IEEE 802.3bm 100GBASE-SR4 Ethernet transmission protocol
- Compatible with IEEE 802.3by 25GBASE-SR Ethernet transmission protocol
- Using 4 pairs of parallel multimode optical fiber transmission, the distance can reach up to 70m (OM3) or 100m (OM4)
- Power consumption less than 2W (100G QSFP28 SR4 module) or 1W (each 25G SFP28 SR module)
- Commercial grade operating temperature range
- Power supply voltage 3.3V
- Comply with RoHS environmental protection standard (lead-free)
| P/N | Description |
|---|---|
| FYG4C-100MxxxTH | 100G QSFP28 to 4x 25G SFP28 AOC |
Additional Information
| Application | |
|---|---|
| Form Factor | |
| Media Type | |
| Product Type | |
| Protocol | |
| Reach | |
| Wavelength |
