200G QSFP56 LR4 EML LWDM4 10km/20km SMF LC Optical Transceiver

FIBERSTAMP 200G QSFP-DD PSM8 optical transceiver modules are used for medium to long distance interconnections in data centers and are compliant with 100G PSM4 MSA specification and 200G Ethernet transport protocols, as well as compatible with 8x10G/25G Ethernet and InfiniBand QDR/EDR transport protocols. The series uses 8 pairs of parallel single-mode fiber optic transmission with a central wavelength of 1310nm and distances up to 2km or 10km (both with FEC on), with optional industrial grade operating temperature range.

Facebook Linkedin Youtube Twitter

Description

  • Hot-pluggable, full-duplex transceiver module packaged in QSFP-DD form factor
  • 8-channel 1310nm DML and PIN
  • Transmission rate up to 25.78125Gbps per channel
  • Built-in CDR circuitry for receive and transmit channels, supporting CDR bypass
  • Compliant with QSFP-DD MSA, CMIS, 100G PSM MSA specification and 200G Ethernet transport protocol
  • Compatible with 8x10G/25G Ethernet and InfiniBand QDR/EDR transport protocols
  • Uses 8 pairs of parallel multimode fiber for transmission over distances up to 2km or 10km (both with FEC on)
  • Power consumption less than 6W (2km version) or 6.5W (10km version)
  • MPO24/PC optical connectors
  • Commercial and industrial grade operating temperature range selectable
  • Supply voltage 3.3V
  • RoHS compliant (lead-free)

Additional Information

P/N Description
FBH-200L4K10C 200G QSFP56 LR4 EML LWDM4 10km optical transceiver
FBH-200L4K20C 200G QSFP56 LR4 EML LWDM4 20km optical transceiver
Application

Form Factor

Media Type

Interface

Product Type

Protocol

,

Reach

Wavelength
