56G QSFP+ Active Optical Cables 4x14G NRZ, 100Meters(328ft)
FIBERSTAMP 56G QSFP+ AOC active optical cable is used for short-distance interconnection between internal devices in the data center. It complies with the 4x16GFC fiber channel transmission protocol and is compatible with the InfiniBand FDR transmission protocol. This series of products uses 4 pairs of parallel multimode optical fiber transmission, and the distance can reach up to 100m (OM3) or 150m (OM4).
Description
- An active optical cable assembly integrating a 56G QSFP+ SR4 optical transceiver module at both ends
- Each side contains 4 channels of 850nm VCSEL and PIN
- The transmission rate per channel can reach up to 14.0625Gbps
- Compliant with QSFP+ MSA (SFF-8436) and 4x16GFC fiber channel transmission protocol
- Compatible with InfiniBand FDR transport protocol
- Using 4 pairs of parallel multimode optical fiber transmission, the distance can reach up to 100m (OM3) or 150m (OM4)
- Power consumption is less than 1.5W (each 56G QSFP+ SR4 optical module)
- Commercial grade operating temperature range
- Power supply voltage 3.3V
- Comply with RoHS environmental protection standard (lead-free)
| P/N | Description |
|---|---|
| FYF-F56MxxxC | 56G QSFP+ AOC |
Additional Information
| Application | |
|---|---|
| Form Factor | |
| Media Type | |
| Product Type | |
| Protocol | |
| Reach | |
| Wavelength |
